LangSmith

Learn how to export LLM Gateway traces to LangSmith using OpenTelemetry integration.

This guide provides instructions for integrating LangSmith with the TrueFoundry AI Gateway to export OpenTelemetry traces.

What is LangSmith?

LangSmith is LangChain’s observability and evaluation platform for LLM applications. It provides comprehensive tracing, debugging, and monitoring capabilities to help teams build reliable AI applications.

Key Features of LangSmith

• LLM Tracing: Capture detailed traces of all LLM interactions including inputs, outputs, latency, and token usage with automatic instrumentation
• Evaluation & Testing: Run evaluations on your LLM outputs with custom evaluators, datasets, and automated testing pipelines
• Prompt Hub: Version control and manage prompts with collaboration features and A/B testing capabilities

Prerequisites

Before integrating LangSmith with TrueFoundry, ensure you have:

1. TrueFoundry Account: Create a Truefoundry account and follow the instructions in our Gateway Quick Start Guide
2. LangSmith Account: Sign up for a LangSmith account
3. LangSmith API Key: Generate a workspace-scoped API key from your LangSmith settings (covered below)

Understanding the LangSmith Hierarchy

LangSmith organizes resources in three levels. Knowing where your API key is scoped and where your traces will land helps avoid empty dashboards:

Organization   ← Top level (your LangSmith org)
   └── Workspace   ← Mid level (e.g. "Personal", "Production")
          └── Project   ← Where traces actually land (e.g. "default", "truefoundry")

• Every LangSmith account comes with a default workspace called Personal, so you usually do not need to create a new one.
• Traces sent through the OTEL endpoint land in the workspace your API key is scoped to, and in the default project unless you override it with a header (see Route Traces to a Specific Project).
• You can find your workspace ID in the URL bar after /o/, or under Settings → Workspaces.

Integration Steps

TrueFoundry AI Gateway supports exporting OpenTelemetry traces to LangSmith, allowing you to monitor and analyze your LLM requests in LangSmith’s observability platform.

1. Create a Workspace-Scoped API Key in LangSmith

   1. Log into your LangSmith dashboard.
   2. Navigate to Settings → API Keys and click Create API Key.
   3. Fill in the dialog as follows:
      • Description: any recognizable name, for example tfy-api-key.
      • Key Type: select Service Key (tied to a service principal, recommended for automation and CI workflows).
      • Scope for Service Key: choose Specific Workspaces, then pick the workspace you want traces to land in (e.g. Personal).
      • Expiration Date: pick a duration that matches your security policy (Never, 30d, 90d, 1 year, or Custom).
   4. Click Create API Key and copy the generated key — you will not be able to view it again.



   You do not need to type the workspace ID anywhere — selecting Specific Workspaces automatically scopes the key to the chosen workspace.

2. Configure OTEL Export in TrueFoundry

   1. Go to AI Gateway → Controls → Settings in the TrueFoundry dashboard.
   2. Scroll down to the OTEL Config section and click the edit button.
   3. Enable the OTEL Traces Exporter Configuration toggle.
   4. Select HTTP Configuration.
   5. Enter the LangSmith traces endpoint: https://api.smith.langchain.com/otel/v1/traces
   6. Set Encoding to Proto.


3. Configure Headers

   Add the required header for LangSmith authentication:

   Header	Value
   x-api-key	Your workspace-scoped LangSmith API key from Step 1

   Click Save to apply your configuration.

4. Verify the Integration

   1. Make some requests through the TrueFoundry AI Gateway.
   2. Navigate to the Monitor section in TrueFoundry to verify traces are being generated.
   3. Log into your LangSmith dashboard and open the workspace you scoped the key to.
   4. Open the Projects section and confirm traces from TrueFoundry are appearing — by default they will land in the default project.



Route Traces to a Specific Project

By default, traces land in the default project of the workspace your API key is scoped to. To send traces to a different project (for example, an existing truefoundry project), add a second header alongside x-api-key in the TrueFoundry OTEL config:

Header	Value
x-api-key	Your workspace-scoped LangSmith API key
Langsmith-Project	The target project name (e.g. truefoundry)

If the project name does not exist yet in the selected workspace, LangSmith will create it on the first ingested trace.

Configuration Options

LangSmith Endpoint

LangSmith uses a single endpoint for OTEL trace ingestion:

Configuration	Value
Traces Endpoint	https://api.smith.langchain.com/otel/v1/traces
Protocol	HTTP
Encoding	Proto / JSON
